Summary

Scale side drawings of cut-lines for the original model designed at 47N and three new models that will work better ten degrees further south, especially with the addition of a black bottom or black heat sinks in the front corners. Northern model fits in turkey bag feet-first, more southerly models go into the bags sideways.

Drawing done in Google Sketch-up, by Elizabeth Foster, to help Sharon Cousins and the EZ-3 Solar Cooker. The drawing may be freely used, as long as it is presented as a drawing for variations on the EZ-3 Solar Cooker.

Licensing:

This file is copyrighted. The copyright holder of this file allows anyone to use it for any purpose, provided that {{{1}}}.


...it is presented as a drawing for variations of the EZ-3 Solar Cooker.
